Name:Aluminum Handle Pn16 Butterfly Valve Design Standards API 609100mm butterfly valve

Design confirms:API 609, BS EN 593, MSS SP-67, BS5155Top

Flange:ISO5211 or factory standard

Tightness check:API 598, ISO 5208, EN12266-1, DIN3230, BS5155

Face-to-face conform:API 609, ISO 5752, BS EN 558, BS 5155, MS SP-67, DIN3202

Normal pressure:PN10/PN16/PN25 or 10Bar/16Bar/25Bar or class 125,150

Nominal dlameter:DN25~DN1200 (1

Operator:Handle lever, worm gearbox(reducer), electric or pneumatic actuators etc

Sultable medlum:Petroleum, chemical industry, water, oil, gas etc.

Working temperature:-45 to 200 CelsiusCast Iron(CI): ASTM A126CL. B, DIN1691 GG25, EN 1561 EN-CGJL-200, GB12226

Body/Dlsc:HT200; Ductile Iron(DI): ASTM A536 65-45-12, DIN 1693 GGG40, EN1563 EN-GJS-400-15, GB12227 QT450-10Zinc Plated Carbon Steel;

Stainless Steel: ASTM A276 TypeStem:316/304/410/420, ASTM A582 Type 416Seat:NBR, EPDM, Neoprene, Viton, PTFE, BUNA, Hypalorn

Bushlng:PTFE, Nylon, Lubricated Bronze
