Name:Bidirectional seal non rising stem knife gate valve purposse, 12 gate valve dimensions

Pressure:PN10 & 150PSI &JIS10K

Slze range:Standard from DN50 to DN1200 & 2

Body:GGG40,WCB solid solution,CF8 solid solution,F8M solid solution

Gate:SS304 solid solution,SS316 solid solution

Stem:SS420;F304 solid solution,F316 solid solution

Pneumatlc:ANSI 1045 chrome plated

Seat:EPDM,Metal, Viton,PTFE,NBR

Support plate:A36 epoxy baked

Operated type:Handwheel,Pneumatic,Gear,Bare shaft.

Structure:Uni-directional & Bi-directional.

Standard flange connectlon: EN1092 PN10 & ANSI B16.5 (class150) & JIS (10K).

Maximum working pressures::DN 50 to DN 250: 10 bar ,DN 300 to DN 450:7 bar,0N 500 to DN 600:4

bar, DN 700 to DN 900: 2 bar,DN 1000 to DIN 1200: 1 bar

Maximum working temperatures:Nitril:80°C, NBR:110 °C EPDM:110°C , PTFE:150 °C
