Test Chambers are high customised product & prices depends upon the specific requirements, quote will be shared after understanding technical requirements, hence One Dollar is mentioned request to reach us for quotation & technical discussion for requirements.

Internal Volumes(L)

TCU

Temperature range

Internal Material

Material

Temperature Fluctuation ±0.1°C
Temperature uniformity

Temperature

External Material

Thermal Insulation

Fan

Refrigeration Compressor

Internal test chamber is manufactured with

Stainless steel

Exterior material shall be made of min 2mm thick
CRCS with powder coated panels/door with impressive

precision & aesthe
cs

Internal test chamber and outer body is isolated
using mineral wool ensuring no air pockets and zero

conduction and heat losses

Single moulded light weight high cfm coaxial fan for

uniform air circula
on.
Danfoss, Frascold and Bitzer
Refrigerant R404a and R23
Cooling mode Air-Cooled/Water Cooled

Evaporator

Evaporator heat exchanger coils are made with
oxidize free materials with full collared bullet
expanded forhighly efficient heat transfer and higher

efficiency.

Heater
Working Temprature

50 liters to 1400 liters

power Supply

-40°C to 180°C and - -70°C to 180°C

Ramp rate 1/2/3//4/5 °C/Min

7” Red Lion (HMI) & Siemens (PLC)
< 1000 Litres: ≤1.5°C.
1000 to 2000 Litres: ≤2.0°C.
> 2000 Litres: ≤2.5°C.

25-30 °C AND 10-90% RH

Controller

Inconel material sheathed/ bare nichrome air
heaters to achieve the set temperature.

Power requirement: 415VAC /-5%,
3 Phase 50/60 Hz, 4 wire E.
