TRIPLE ECCENTRIC BUTTERFLY VALVE, TRIPLE OFFSET BUTTERFLY VALVE, BUTTERFLY VALVE CONNECTION
Availability: in stock
Trade with confidence on Abraa
Safe and secure payments using Abraa safe trade systems
Supplier verification not completed
Pay only through Abraa to stay protected. Never pay a supplier by direct transfer.
Secure Payment
Pay through Abraa, never by direct transfer to a supplier.
Product Inspection
Book a check before shipping to confirm quality and quantity.
Buyer Protection
Get support and refunds if goods arrive not as described.
Verified Suppliers
Licence, address and on-site checks by the Abraa team.
Product Specification
Product Descriptions
Name:Triple eccentric butterfly valve, triple offset butterfly valvve, butterflyvalve connection
Design confirms:API 609, BS EN 593, MSS SP-67, BS5155
Top Flange:ISO5211 or factory standard
Tightness check:API 598, ISO 5208, EN12266-1, DIN3230, BS5155
Face-to-face conform:API 609, ISO 5752, BS EN 558, BS 5155, MS SP-67, DIIN3202
Normal pressure:PN10/PN16/PN25 or 10Bar/16Bar/25Bar or class 125/1150
Nominal dlameter:DN25~DN1200 (1
Operator:Handle lever, worm gearbox(reducer), electric or pneumatic actuators etc
Sultable medlum:Petroleum, chemical industry, water, oil, gas etc.
Working temperature:29 to 425 Celsius
Body/Dlsc:ASTM A216 WCBZinc Plated Carbon Steel;
Stainless Steel: ASTM A276 TypeStem:316/304/410/420, ASTM A582 Type 416
Seat:NBR, EPDM, Neoprene, Viton, PTFE, BUNA, Hypalon
Bushing:PTFE, Nylon, Lubricated Bronze
\
