Home /  Safety & Security  >  Security & Surveillance  >  Detectors & Scanners / X-RAY BAGGAGE SCANNER X RAY BAGGAGE SCANNER FOR AIRPORT LUGGAGE SECURITY CHECKING 150160

X-ray baggage scanner x ray baggage scanner for airport luggage security checking 150160

0 Reviews

Warranty: YES
Country of shipping : China
Request for quotation
Payment options

Product Specification

Brand PEACENTURY
Warranty YES

Product Description


PRODUCT:X Ray Baggage ScannerTUNNEL SIZE:1500(W)*1600(H)mm
X RAY LEAKAGE:<1.6μGy/hCONVEYOR MAX LOAD:500 KGS
FILM SAFETY:ISO 1600 Film-safePENETRATION:34mm Steel
ANODE VOLTAGE:100-160KVSYSTEM POWER:220VAC (±10%) 50±3HZ
PACKGAE:Plywood Case


X-ray baggage scanner x ray baggage scanner for airport luggage security checking



General Specification
Tunnel Size1500(W)*1600(H)mmConveyor Speed0.22m/s
Conveyor Max Load200kgDose per Inspection< 1.7μGy/h
Resolution< 0.0787mm Copper WireSpatial resolutionLevel: dia1.0mm, Vertical: dia1.0mm
Penetrate resolutionDia 0.254mmPenetration≥ 38-40mm Steel
Film SafetyGuarantee 1900FilmX-ray Leakage<0.05μGy/h (at a distance of 5cm From external housing)
Multi-energetic distinguish objectsorganic objects in orange, inorganic objects in blue, mixture in greenHigh-energy/low energeswitch from high energy to low energy



Advantages:
1. Famous brand spare parts
a. Hamamatsu brand detector from Japan
2. Protective cover on lead curtain to avoid lead pollution
3. Sound and light alarm
4. Local network supported



General Specification

Tunnel Size: 1000(W)*1800(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 200kg
Dose per Inspection < 1.7μ Gy/h
Resolution < 0.101mm Copper Wire
Spatial resolution: Level: Dia1.3mm, Vertical: Dia1.0mm
Penetrate resolution: Dia 0.511mm
Penetration: 34mm Steel
Film Safety: Guarantee ISO1600 Film
X-ray Leakage: <0.1 μ Gy/h (at a distance of 5cm From external housing)



X-ray Generator

Generate direct: Downward
Generate anger: 80 degree
Anode Voltage: 100~160Kv
Anode power: 0.4 to 1.2mA
Cooling / Duty Cycle: Oil Cooling /100%



Image System

X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 12bit Deep
Monitor: High Resolution Color, LCD Accord, 17 inch
Image Processing: Edge enhancement, image strengthening, image lightening , reducing darkening, image returning, image retrieval.
Image Grey Level: 4096
Image Max Resolution: 1024 * 1280 pixel
Image Processing: 24bit for processing real time
Image storage: Storage 60000 pictures in real time
Zoom: 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation
Multi-energetic distinguish objects: Organic objects in orange, inorganic objects in blue, mixture in green
High-energy/low energy: Switch from high energy to low energy
Assist to detect drug and explosive powder



Installation Data

Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
Operation Power: 220VAC(± 10%)50± 3Hz
Power Consumption: 1.0 KW (max), 1.0KW(working)
Noise: <58dB.



SHENZHEN HEPING CENTURY TECHNOLOGY CO., LTD (PEACENTURY)is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine technology, metal detection technology, explosive detection, liquid detection and relative security services.

We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.

We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .

Contant us :
Mob/WhatsApp/Wechat: 86 17820602014
Email:info@peacentury.com
www.peacenturydetector.com
anya@peacentury.com

Business Type:Manufacturer& International Trading Company
Location:Shenzhen,China (Mainland)
Main Products:Walk Through Metal Detector,X-Ray Baggage Scanner,Hand Held Metal Detector,Under Vehicle Inspection System,Hydraulic Rising Bollard,Hydraulic Road Blocker,Tire Killer,Gold Detector,Barrier Gate etc.
