BXZ Series Backpack Core Drilling Rig
1、Introduction of BXZ Series Backpack Core Drilling RigBXZ series backpack drilling rig is a portable core drilling rig with backpack, which is mainly suitable for borehole sampling in shallow geological exploration such as mineral exploration, geological research and engineering exploration in mountainous areas where transportation and energy are inconvenient.。‌Features of BXZ Series Backpack Core Drilling Rig2.1 Compact structure, small size, light weight, easy to carry.2.2 Using well-known brand gasoline engine, energy saving and high efficiency, the quality of drilling rig is guaranteed.2.3 Equipped with high quality drill pipe and bit, it is durable and more efficient.3、Parameters of BXZ Series Backpack Core Drilling RigModel BXZ-1 BXZ-1L BXZ-1C BXZ-2 BXZ-2LStyle One-person handrail Steel column type One-person handrail Two-person handrail Steel column typeEngine brand Mitsubishi Mitsubishi Hengyue Kohler KohlerPower 3.2HP 3.2HP 3HP 7.75HP 7.75HPDrill pipe 32*700mm 32*700mm 25*800mm 32*700mm 32*800mmHole diameter 33-46mm 33-46mm 26-36mm 33-120mm 33-120mmMax.sampling depth 20m 20m 15m 20m 30mHost weight 8kg 25kg 12kg 30kg 50kgNote: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
