Name:carbon steel 4 flanged knife gate valve cv, resilient gatte valve

Pressure:PN10 & 150PSI &JIS1OK

Slze range:Standard from DN50 to DN1200 & 2

Body:GGG40,WCB solid solution,CF8 solid solution,CF8M solid solution
Gate:SS304 solid solution,SS316 solid solution

Stem:SS420;F304 solid solution, F316 solid solution

Pneumatlc:ANSI 1045 chrome plated

Seat:EPDM,Metal, Viton,PTFE,NBR
Support plate:
A36 epoxy baked

Operated type:Handwheel,Pneumatic, Gear, Bare shaft.
Structure:Uni-directional & Bi-directional.

Standard flange connectlon: EN1092 PN10 & ANSI B16.5 (class 150) & JIS (10K).
Maximum working pressures::DN 50 to DN 250: 10 bar,DN 300 to DN 450: 7bar,DN 500 to DN 600:4

bar, DN 700 to DN 900: 2 bar,DN 1000 to DN 1200: 1 bar

Maximum working temperatures:Nitril:80°C, NBR:110 °C EPDM:110°C, PTFE:150 °C
